內置換熱鍋爐
功能特點Functional features
長壽命 Longevity
爐水只作熱載體使用，在運行時，水中的氧加熱析出。排出爐外，爐內長期使用不會發生氧腐蝕，一次性加入熱媒水，有限少量的鈣鎂離子亦被加熱軟化，運行時爐水不增不減，因此鍋爐內部不發生結垢，延長了鍋爐使用的壽命，是一般鍋爐壽命1.5~2倍。
Boiler water is only used as thermal carrier,when it is heated,the oxygen will be decomposed and discharged outso oxygen corrosion wonnot happen,when thermal media water is added once.a few calcium and magnesuim ions will be heated and be inteneratedboiler water wonnotdecrease or increase when boiler is workingso there is no furring inside,all these contribute to long life efficiency star boiler’s life is about 3times longer than regular boilers heat exchanger is made of stainless steel tubes which are corrosion-resistant and rust- free,offering clean and hygienic hot domestic water.
機組常壓運行，安全可靠
work under normal pressureit’ssafeandreliable
鍋爐上部設有膨脹水箱，水位自動控制，無壓運行，安全可靠，簡化了繁雜的報批手續。
An expansion tank is equipped at the topwater level can be controlled automaticallyit works without pressure,so it’s safe and reliabletedious report and endorse procedures are simplified.
結構緊湊，安裝簡便，工程費用省
Compact structure,easy to mount and low engineering cost.
間接加熱熱水鍋爐模塊化設計，高性能換熱組件，機組結構緊湊，使產品易于運輸、安裝，在小空間內，多臺機組可并聯使用，其工藝系統也很簡潔，免去了換熱站的設計與施工，工程費用省。
微結構Structure
間接加熱熱水鍋爐的下半部結構與普通鍋爐一樣，由燃燒室與傳熱管組成，上半部分裝有熱交換器，爐體上部裝設有膨脹水箱。由于鍋爐整體是在常壓狀態下，故絕對安全。爐內的熱媒介在鍋爐運行的全過程中不進、不出，在鍋爐的傳熱管與熱交換器之間傳遞熱量。爐內的熱媒介經加熱完全脫氧和軟化，無腐蝕，無水垢，使鍋爐壽命長達20多年。內置換熱器嚴格按照管殼式換熱器制造標準制造，殼程和管程分別作水壓試驗
The structure of lower part of the indirect heating boiler is the same as the regular one ,it’s composed of the firebox and heat transfer tubes, the upper part is equipped with a heat exchanger, there is also an expansion tank at the top. Generally, the boiler works under normal pressure, so it’s absolutely safe, the thermal media in the boiler isn’t in or out when the boiler is working, it transfers the heat between heat transfer tube and heat exchange, after being heated in furnace heat medium completely deoxidization and softening, and there is no furring and oxygen corrosion, these make the using life of the boiler last as long as 20yearsbuild in heat exchanger is manufactured to comply with manufacturing standard of shell-and -tube heatexchange tube pass and shell pass are put to test of water pressure.
注：表中數據及圖片僅供參考，產品以實物為準，如因改機型而變更恕不另行通知。
